Soft Seated Ball Valves

FlowAx’s Soft Seated Ball Valves are engineered to provide superior sealing performance and reliability in various industrial applications. Designed with a soft seat, typically made from materials like PTFE, these valves ensure a tight, bubble free seal, even under low pressure conditions. The soft seat design also minimizes wear and tear, enhancing the valve’s durability and longevity. Ideal for handling a range of media, including corrosive and abrasive substances, FlowAx’s soft seated Ball Valves offer excellent chemical resistance, ensuring safe and efficient flow control. Whether used in chemical processing, oil and gas, or water treatment, these valves are a dependable choice for achieving precise and reliable flow management.

FlowAx Control LLP offers for Soft Seated Ball Valves materials used for this product line, including but not limited to:
Carbon Steel such as A-105 or WCB.
Stainless Steel such as CF8, CF8M or F316. F316L
Low Carbon Stainless Steel such as CF3, CF3M, CG3M.
Duplex Steel F51 , F53 , F55 , Gr4a, Gr5a, Gr6a
Bronze – Aluminium Bronze AB1, AB2 , Gunmetal LG2,LG4

Design Features

Standard Floating Ball valves in accordance with API 608, API6D & MSS-SP-72 for flanged and BW ends from 1/2” up to 8”. Test in accordance with API 598.
Standard Floating Ball Valves in accordance with MSS-SP-110 for threaded and socket weld ends from 1/4” up to 4”. Test in accordance with MSS-SP-110
Fire Safe Floating Ball valves in accordance with API-6D & API-608 for flanged and BW ends from 1/2 up to 8”. Test in accordance with API-598.
Fire Safe Floating Ball valves in accordance with API-608 or ASME B16.34 for threaded and socket well ends from 1/2” up to 2”. Test in accordance with API-598
